Ride-On Floor Scrubber

    Ride-On Floor Scrubber

    M5 Ride-On Floor ScrubberKeywords: Floor Scrubber, Ride-On Floor Scrubber, Electric Floor Scrubber1. Product OverviewThe M5 Ride-On Floor Scrubber is designed for deep cleaning of large floor areas, providing high efficiency and reliable performance. Suitable for a variety of flat surfaces including epoxy, terrazzo, tile, and marble, the M5 ensures a thorough clean while saving labor and time. Its ride-on design allows operators to work comfortably over extended periods.Technical SpecificationsNo.ItemSpecification1NameRide-On Floor Scrubber2FunctionDeep Cleaning3Applicable FloorEpoxy, terrazzo...
  • Share:
  • Contact us Inquiry
  • WhatsApp:+8618908661693

M5 Ride-On Floor Scrubber

Keywords: Floor Scrubber, Ride-On Floor Scrubber, Electric Floor Scrubber


1. Product OveRView

The M5 Ride-On Floor Scrubber is designed for deep cleaning of large floor areas, providing high efficiency and reliable performance. Suitable for a variety of flat surfaces including epoxy, terrazzo, tile, and marble, the M5 ensures a thorough clean while saving labor and time. Its ride-on design allows operators to work comfortably over extended periods.





Technical Specifications

No.ItemSpecification
1NameRide-On Floor Scrubber
2FunctionDeep Cleaning
3Applicable FloorEpoxy, terrazzo, tile, marble, and other flat surfaces
4Cleaning Efficiency3600 m²/h
5Scrubbing Width530 mm
6Suction Width800 mm
7Brush Speed150 rpm
8Brush Motor Power550 W
9Suction Motor Power600 W
10Drive Motor Power500 W
11Travel Speed0–7 km/h
12Water Tank CapacityClean Water Tank: 90 L, Dirty Water Tank: 100 L
13Maximum Climbing Capacity15%
14Turning Radius500 mm
15Noise Level60 dB(A)
16Continuous Work Time3–5 h
17Machine Dimensions (L×W×H)1300 × 720 × 1420 mm
18Voltage24 V
19Battery Capacity2 × DC12V 100Ah
20Vehicle Weight197 kg


Key Features

  • High Cleaning Efficiency: Cleans up to 3600 m² per hour, ideal for large facilities.

  • Ride-On Comfort: Ergonomic seating reduces operator fatigue during prolonged use.

  • Deep Cleaning Capability: Brush system removes dirt, grime, and residues from various floor surfaces.

  • Electric Drive: Quiet operation (60 dB) and energy-efficient motor system.

  • Durable Design: Sturdy frame and high-quality brush components ensure long-term performance.

  • Large Water Capacity: 90 L clean water and 100 L dirty water tanks minimize refilling interruptions.

  • Maneuverable: Compact design and 500 mm turning radius allow easy operation in tight spaces.

  • Safe and Reliable: Stable climbing ability up to 15%, suitable for slightly inclined floors.


4. Application Scenarios

The M5 Ride-On Floor Scrubber is ideal for:

  • Commercial buildings and office spaces

  • Shopping malls and supermarkets

  • Airports and train stations

  • Schools, hospitals, and hospitals

  • Factories, warehouses, and logistics centers

  • Public spaces such as exhibition halls and sports arenas



FAQ

Q1: What types of floors can the M5 clean?
A1: Suitable for epoxy, terrazzo, tile, marble, and other flat surfaces.

Q2: How long can the M5 operate continuously?
A2: 3–5 hours depending on battery charge and cleaning conditions.

**Q3: What

is the cleaning width?**
A3: The scrubber has a 530 mm scrubbing width and 800 mm suction width for efficient cleaning.

Q4: What type of power does the M5 use?
A4: It uses a 24V electric system powered by 2 × DC12V 100Ah batteries.

Q5: How fast can the M5 travel?
A5: The travel speed ranges from 0 to 7 km/h.

Q6: Can it handle slopes?
A6: Yes, the maximum climbing ability is 15%.

Q7: What is the noise level during operation?
A7: The M5 operates quietly at approximately 60 dB(A).



Technical Specifications

No.ItemSpecification
1NameRide-On Floor Scrubber
2FunctionDeep Cleaning
3Applicable FloorEpoxy, terrazzo, tile, marble, and other flat surfaces
4Cleaning Efficiency3600 m²/h
5Scrubbing Width530 mm
6Suction Width800 mm
7Brush Speed150 rpm
8Brush Motor Power550 W
9Suction Motor Power600 W
10Drive Motor Power500 W
11Travel Speed0–7 km/h
12Water Tank CapacityClean Water Tank: 90 L, Dirty Water Tank: 100 L
13Maximum Climbing Capacity15%
14Turning Radius500 mm
15Noise Level60 dB(A)
16Continuous Work Time3–5 h
17Machine Dimensions (L×W×H)1300 × 720 × 1420 mm
18Voltage24 V
19Battery Capacity2 × DC12V 100Ah
20Vehicle Weight197 kg


Key Features

  • High Cleaning Efficiency: Cleans up to 3600 m² per hour, ideal for large facilities.

  • Ride-On Comfort: Ergonomic seating reduces operator fatigue during prolonged use.

  • Deep Cleaning Capability: Brush system removes dirt, grime, and residues from various floor surfaces.

  • Electric Drive: Quiet operation (60 dB) and energy-efficient motor system.

  • Durable Design: Sturdy frame and high-quality brush components ensure long-term performance.

  • Large Water Capacity: 90 L clean water and 100 L dirty water tanks minimize refilling interruptions.

  • Maneuverable: Compact design and 500 mm turning radius allow easy operation in tight spaces.

  • Safe and Reliable: Stable climbing ability up to 15%, suitable for slightly inclined floors.


4. Application Scenarios

The M5 Ride-On Floor Scrubber is ideal for:

  • Commercial buildings and office spaces

  • Shopping malls and supermarkets

  • Airports and train stations

  • Schools, hospitals, and hospitals

  • Factories, warehouses, and logistics centers

  • Public spaces such as exhibition halls and sports arenas


FAQ

Q1: What types of floors can the M5 clean?
A1: Suitable for epoxy, terrazzo, tile, marble, and other flat surfaces.

Q2: How long can the M5 operate continuously?
A2: 3–5 hours depending on battery charge and cleaning conditions.

**Q3: What

is the cleaning width?**
A3: The scrubber has a 530 mm scrubbing width and 800 mm suction width for efficient cleaning.

Q4: What type of power does the M5 use?
A4: It uses a 24V electric system powered by 2 × DC12V 100Ah batteries.

Q5: How fast can the M5 travel?
A5: The travel speed ranges from 0 to 7 km/h.

Q6: Can it handle slopes?
A6: Yes, the maximum climbing ability is 15%.

Q7: What is the noise level during operation?
A7: The M5 operates quietly at approximately 60 dB(A).
