STQ5048XXYNBEV Electric Mini Box Truck – Product Brochure
Manufacturer: Hubei Sanhuan Automobile Co., Ltd.
Model: STQ5048XXYNBEV / STQ5048XXYN6BEV
Keywords: Electric Mini Box Truck, EV Cargo Van, Small Electric delivery truck
The STQ5048XXYNBEV is a fully electric mini box truck designed for efficient urban logistics and short-to-medium distance cargo delivery. It combines a high-efficiency electric drivetrain, modern cab design, and durable cargo box, ensuring reliability, low operating costs, and eco-friendly operations.
Key Features:
Fully electric, zero emissions
4×2 drive with high stability
Modern single-row high-roof cab with multimedia and air conditioning
Cargo box designed for urban delivery and logistics operations
Safety features including ABS and dual batteries for reliability
This EV cargo van is ideal for businesses seeking a sustainable and cost-effective delivery solution.
| Parameter Category | Item | Unit | Specification |
|---|---|---|---|
| Vehicle | Model | / | STQ5048XXYNBEV / STQ5048XXYN6BEV |
| Drive Type | / | 4×2 | |
| Weight | Gross Vehicle Weight | kg | 4495 |
| Curb Weight | kg | 3040 | |
| Dimensions | Length | mm | 5995 |
| Width | mm | 2200 | |
| Height | mm | 3150 | |
| Wheelbase | mm | 3360 | |
| Performance | Maximum Speed | km/h | 88 |
| Maximum Gradeability | ° | 23 | |
| Chassis & Motor | Motor | / | Yuchai Xinlan |
| Rated / Peak Power | kW | 60 / 115 | |
| Battery | kWh | CATL 100.46 / CALB 81.87 | |
| Battery Layout | / | Underfloor | |
| Cabin | Type | / | Single-row, high-roof standard |
| Model | / | F2 (1900mm width) | |
| Standard Features | / | Two-point suspension, multimedia with reversing camera, air conditioning, power windows, central locking, optional aerodynamic deflector | |
| Front Axle | Type | / | Hydraulic / Air brakes |
| Load Capacity | kg | 1800 | |
| Rear Axle | Type | / | Electric drive axle, Hydraulic / Air brakes |
| Load Capacity | kg | 3500 | |
| Gear Ratio | / | 16.015 | |
| Frame | Cross-section Size | mm | 162(6)/192(5) |
| Suspension | Leaf Springs | / | 3 / 3+2 |
| Wheels & Tires | Tire Type | / | Steel wire tires |
| Quantity | / | 6 | |
| Size | / | 7.00R16LT 8PR | |
| Steering | Type | / | EPS |
| Brakes | Brake Type | / | Hydraulic / Air brakes, with ABS |
| Service Brake | / | 82° Hydraulic, 100° Air | |
| Parking Brake | / | Manual cable / Air cut-off | |
| Electrical System | System Voltage | V | 24 |
| Battery | / | 75AH Dual Batteries | |
| Cargo Box | Length | mm | 4150 |
| Material | / | Q235 Steel | |
| Floor Thickness | mm | 2 | |
| Other Equipment | / | / | Triangle warning sign, tool kit |
High-performance 60/115 kW motor delivers strong torque
Dual battery system ensures reliability and longer operating time
Zero emissions, ideal for urban delivery zones
4.15m cargo length, robust Q235 steel construction
2mm thick floor for durability
Designed for small-to-medium packages and daily urban logistics
Single-row high-roof cab offers spacious 1900mm width
Multimedia, AC, power windows, and central locking for driver comfort
Two-point suspension improves ride quality
Front hydraulic / air brakes and ABS for secure stopping
Electric drive axle enhances stability and efficiency
EPS steering system for smooth maneuvering
Parking brake manual control ensures safe parking on slopes
No fuel cost, reduced maintenance compared to ICE vans
Durable steel frame and chassis components extend vehicle life
Suitable for fleet deployment in urban environments
Urban last-mile delivery
E-commerce parcel transportation
Cold chain or light cargo distribution
Warehousing and industrial area logistics
Eco-friendly urban freight solutions
Q1: What is the maximum speed of this EV cargo van?
A: The maximum speed is 88 km/h, sufficient for city and suburban routes.
Q2: What is the battery capacity and range?
A: Battery options include CATL 100.46 kWh or CALB 81.87 kWh, with underfloor installation for weight balance. Range depends on driving conditions and load.
Q3: How much cargo can it carry?
A: Maximum payload is 1455 kg, with rear axle load capacity of 3500 kg.
Q4: What safety features are included?
A: ABS brakes, dual batteries, EPS steering, hydraulic/air brake systems, manual parking brake.
Q5: Is it suitable for urban deliveries?
A: Yes, its compact size, zero emissions, and maneuverability make it ideal for city logistics.
Q6: What is the cargo box size and material?
A: Length 4150 mm, Q235 steel, 2mm floor thickness, ideal for small to medium deliveries.
Q7: What is the cabin configuration?
A: Single-row high-roof (F2) with multimedia, air conditioning, power windows, central locking, and optional aerodynamic deflector.
Q8: How many tires and what type?
A: 6 steel wire tires, size 7.00R16LT 8PR, designed for durability and load capacity.
Q9: What is the system voltage and battery type?
A: 24V system with 75AH dual batteries, suitable for stable power supply and auxiliary systems.
Q10: How eco-friendly is this vehicle?
A: Fully electric, zero emissions, suitable for cities with low-emission zones and environmentally sensitive areas.
