K7-700 Galvanized High-Pressure Cleaning fire truck
Keywords: Mini Electric Fire Truck, Electric Fire Truck, High-Pressure Firefighting Vehicle
The K7-700 Galvanized High-Pressure Cleaning Fire Truck is a compact, multi-functional fire and cleaning vehicle designed for urban sanitation, firefighting, and emergency response. With integrated cleaning, front and rear flushing, rotating top spray, and high-pressure cannon, this vehicle combines electric drive efficiency and durable construction for reliable operation in challenging environments.
| No. | Component | Specification |
|---|---|---|
| 1 | Function | Cleaning + Front Flushing + Rear Flushing + Top Rotating Spray + High-Pressure Cannon |
| 2 | Drive Motor | 1800W high-power heavy-duty motor, optimized for strong output |
| 3 | Rear Axle | Heavy-duty integrated rear axle for enhanced load capacity |
| 4 | Battery | 60V 32Ah, brand-name maintenance-free lead-acid battery (Supower/TianNeng), stable performance and long life |
| 5 | Climbing Ability | ≤15° |
| 6 | Rated Operators | 1 person |
| 7 | Maximum Speed | 25 km/h |
| 8 | Wheelbase | 2100 mm |
| 9 | Color | Orange-yellow |
| No. | Component | Specification |
|---|---|---|
| 1 | Frame & Body | Premium carbon steel, automotive-grade high-temperature baked paint for corrosion resistance |
| 2 | Rear Axle | Custom heavy-duty rear axle for strong load capacity |
| 3 | Braking System | Front and rear mechanical brakes with parking brake |
| 4 | Suspension | Front: reinforced dual-tube shock absorption; Rear: leaf spring non-independent suspension |
| 5 | Tire Specification | Front: 375-12, Rear: 400-12 |
| 6 | Signal Lights | Headlights, front/rear turn signals, brake lights, horn |
| 7 | Vehicle Dimensions | L: 3065 mm × W: 1100 mm × H: 1500 mm |
| 8 | Seats | High-density foam seat |
| No. | Component | Specification |
|---|---|---|
| 1 | Compartment Material | Concealed sliding track galvanized steel |
| 2 | Compartment Dimensions | L: 1700 mm × W: 1000 mm × H: 800 mm |
| 3 | Tank Material | Rotational molded water tank, seamless design, corrosion-resistant, anti-aging; equipped with inlet and drain |
| 4 | Tank Capacity | 700 L |
| No. | Component | Specification |
|---|---|---|
| 1 | Engine | Loncin 420 electric start, 13HP high-performance air-cooled, 4-stroke OHV gasoline engine |
| 2 | Water Pump | Domestic cleaning pump, 250 kg/cm², 15 L/min, adjustable pressure |
| 3 | Electric Pump | 1000W centrifugal pump, high-pressure cannon range ~10 m |
| 4 | Hose Reel | 13-meter heavy-duty dual-arm automatic retractable hose, dual-layer hydraulic hose with protective sleeve |
| 5 | Filter | 80-mesh water filter, clearly positioned for easy maintenance |
| 6 | Spray Device | High-pressure cleaning gun with multiple spray modes (0°, 15°, 25°, 45°, rotating); front flush and rear spray |
| 7 | Water Path Switching | Stainless steel high-pressure ball valve for fast and convenient switching |
Multi-Functional Cleaning & Firefighting: Front/rear flush, rotating spray, high-pressure cannon for versatile operations.
Electric & Gas Hybrid System: Combines high-efficiency electric drive and gasoline engine for extended cleaning/firefighting performance.
Durable Construction: Galvanized compartment, high-grade carbon steel frame, corrosion-resistant coating.
Portable & Compact: Suitable for narrow streets, alleys, and crowded urban areas.
User-Friendly Operation: Single-person operation with ergonomic seating, digital display, and accessible controls.
High Safety Standards: Mechanical brakes, reinforced suspension, and protective compartment design.
The K7-700 High-Pressure Cleaning Fire Truck is suitable for:
Urban streets, sidewalks, and alleys
Construction sites and industrial areas
Schools, parks, hospitals, office complexes, and parking lots
Residential areas, pedestrian paths, and city stations
Guardrails, street furniture, and other public facilities
Q1: What cleaning functions are available?
A1: Front flush, rear flush, rotating top spray, and high-pressure cannon.
Q2: What is the maximum speed?
A2: The vehicle can reach 25 km/h.
Q3: How many operators are required?
A3: The vehicle is designed for single-person operation.
Q4: What is the tank capacity?
A4: The water tank holds 700 liters.
Q5: What type of engine/power system does it use?
A5: Combination of 1800W electric motor and Loncin 420 13HP gasoline engine for cleaning and high-pressure operations.
Q6: What is the climbing ability?
A6: Can climb slopes up to 15°.
Q7: Where can this vehicle be used?
A7: Ideal for urban sanitation, firefighting, industrial cleaning, public parks, and schools.
