CLW J6L 18-Ton Miscellaneous dangerous goods box truck

1. Product OveRView

The CLW J6L 18-ton miscellaneous dangerous goods box truck is specifically designed for safe and reliable transportation of various hazardous and flammable materials. Its high-strength chassis, advanced safety systems, and well-constructed cargo box ensure maximum protection for the cargo, driver, and surrounding environment.

This vehicle is ideal for industrial logistics, chemical plants, municipal services, and specialized cargo operations, offering efficiency, compliance with National VI emissions standards, and operational flexibility. The truck meets all domestic regulatory requirements for miscellaneous hazardous goods transport.

2. Model & Dimensions

3. Chassis Configuration

• Cabin: J6L refined edition, full-floating design, either high-top or flat-top with air-suspension driver seat and middle passenger seat

• Engine: Dachai CA6DH1-24E61, EGR + DOC + DPF + SCR exhaust treatment, engine brake

• Transmission: CA8TAX090F gearbox

• Axles: Ф378 welded front axle with imported ABS, rear 18-layer radial tires 275/80R22.5

• Suspension: 3-airbag front, 4-airbag rear with ECAS electronic control

• Brakes: Front disc / rear wedge-type, AEBS, EBS, ESC

• Safety & Monitoring: LDW (Lane Departure Warning), FCW (Forward Collision Warning), TPMS (Tire Pressure Monitoring System), emergency tire device, static grounding strip, dry powder fire extinguisher

• Cabin Electronics: Automatic air conditioning, LCD instrument panel, electric windows, powered mirrors, T-Box 1.5 telematics, DIN Beidou-compatible navigation

• Speed Limitation: 79 km/h, spark arrester on exhaust, pre-installed exhaust silencer

Cabin Options by Wheelbase:

• 4,700 mm: Full-floating high-top cabin

• 5,300 mm: Full-floating flat-top cabin (optional high-top + 3,000 RMB)

• 5,800 mm: Full-floating flat-top cabin (optional high-top + 3,000 RMB)

4. Cargo Box / Body Configuration

• Structure: Double-layer composite panels, outer cold-rolled steel, inner aluminum panel, reinforced rectangular tube frame, fire-retardant insulation

• Ventilation & Doors: Anti-rain ventilation windows, optional side doors, sealed with dustproof and waterproof sealing strips

• Flooring: Fire-retardant anti-static rubber mat

• Safety Equipment: Fire and smoke alarm in cargo box, anti-theft alarm on cargo doors, static grounding straps, safety signs, hazard labels, reflective markers, fire extinguisher, triangular warning light, exhaust spark arrester

• Cargo Securing: Optional cargo tie-down rings or slots inside the box

• Exterior Protection: Aluminum alloy edge protection around the cargo box

• Compliance: Fully compliant with hazardous materials transport regulations

5. Key Features & Advantages

• Safe Hazardous Material Transport: Designed for transporting miscellaneous dangerous goods with enhanced safety measures

• Advanced Chassis & Cabin: High-strength J6L chassis with multiple safety and driver-assistance systems

• Durable Cargo Box: Double-layer composite structure, fire-retardant and anti-static materials

• Flexible Loading: Multiple cargo securing options and optional side doors for efficient loading/unloading

• Regulatory Compliance: Meets all National VI emission standards and hazardous materials transport regulations

• Operator Comfort & Safety: Air-suspension seats, air conditioning, advanced warning systems, and remote monitoring via T-Box

7. FAQ Section

Q1: What hazardous materials can be transported?

A: This truck is suitable for miscellaneous hazardous goods, including flammable liquids, toxic substances, and other regulated dangerous materials.

Q2: What is the rated payload?

A: The rated payload ranges from 9,990 kg to 10,375 kg, depending on the configuration.

Q3: What safety features are included?

A: The truck includes LDW, FCW, AEBS, EBS, ESC, static grounding, fire extinguisher, fire/smoke alarm, and exhaust spark arrester.

Q4: Can the cabin be upgraded?

A: Yes, depending on the wheelbase, you can choose high-top or flat-top full-floating cabins, with optional high-top upgrade costing 3,000 RMB.

Q5: What are the cargo box dimensions?

A: The cargo box internal length ranges from 6,200 mm to 7,650 mm, width 2,420–2,460 mm, and height 2,200–2,600 mm.

Q6: Is the truck compliant with emission regulations?

A: Yes, it meets National VI emission standards.

Q7: How many passengers can the truck carry?

A: The truck is designed for 2–3 passengers, depending on the cabin configuration.
